79
MAINTENANCE AND LUBRICATION
Oil Check
The oil dipstick and fill tube (1) are located on the left side of the
vehicle.
1. Position the ATV on a level surface.
2. Start the engine and let it idle
for 20-30 seconds.
3. Stop the engine. Remove the
dipstick and wipe it dry with a
clean cloth. NOTE: If your
dipstick is equipped with a
lever lock (2), lift the lock to
remove the dipstick.
4. Reinstall the dipstick
completely, but do not lock it
(if equipped). The dipstick must
be screwed completely in to keep
the angle and depth of the stick
consistent.
5. Remove the dipstick and
check the oil level. Maintain
the oil level in the normal or
safe range (3), depending on
the style of dipstick in your
model. Do not overfill.
6. After reinstalling the
dipstick, be sure to seat
the lever lock (if
equipped).
1
SAFE
ADD 8 OZ
2
3
ADD 8 OZ. NORMAL FULL
3
