3.20
ENGINE
29. Mark the upper jam nut and loosen the lower jam nut. Pull
the shift cable out of the mount.
NOTE: If the upper jam nut is moved, shift cable
adjustment will be required during engine
installation (see Chapter 2 “Shift Cable Inspection /
Adjustment”).
30. Disconnect the transmission gear indicator switch harness.
31. Disconnect the CPS harness.
32. Disconnect the stator / alternator harness.
33. Disconnect the transmission speed sensor harness.
34. Remove the castle nuts from both rear wheel hubs.
Lower
Jam Nut
Mark Upper
Jam Nut
Gear Switch
Connector
CPS
Connector
Stator
Connector
Speed Sensor
Connector
Castle Nut
To Next Page
