134
MAINTENANCE
Battery (if equipped)
WARNING! Improperly connecting or disconnecting battery cables can result in
an explosion and cause serious injury or death. When removing the battery,
always disconnect the negative (black) cable first. When reinstalling the battery,
always connect the negative (black) cable last.
Battery Removal
1. Remove the right side panel
to access the battery. See
page 104.
2. Remove the two plastic
rivets (1) securing the
console panel to the chassis.
3. Remove the plastic rivet (2)
securing the fender to the
chassis.
4. Disconnect the black
(negative) battery cable first.
5. Disconnect the red (positive)
battery cable last.
6. Remove the battery hold-
down strap (3).
To Next Page
