FEATURES
Tools
The belt removal L-wrench
tool and the spare belt, spark
plug and spark plug tool
container are located behind
the left engine compartment
panel.
NOTE: Spare belt and spark
plugs are not provided
with the snowmobile.
When properly engaged in the
bracket, the L-wrench secures
the fender to the console.
To retrieve the L-wrench,
rotate it counter-clockwise and
slide it upward from the
bracket.
Return the L-wrench to the
bracket and rotate it clockwise
when it’s not in use.
The spark plug wrench secures
the spare belt/spark plug tool
container to the front bumper.
Remove the container to add
or access a spare spark plug or
belt.
1. Rotate the spark plug
wrench counter-clockwise
to release it from the
bracket.
2. Pull the wrench upward to
remove it.
3. Tilt the container until the bracket detaches from the bumper tube.
