100
MAINTENANCE AND LUBRICATIO N
Lights
Lower Headlamp Removal / Installation
1. Turn the back of the headlight harness (1) in a
clockwise direction.
2. Pull the harness assembly out from the headlight
assembly.
3. Remove the headlamp and replace with a
new headlamp.
4. Install the new headlamp and harness assembly
into the headlight assembly. Turn the headlight harness
counterclockwise to secure the headlamp into place.
Tailligh t /Brakelight Lamp Replacement
If the t aillight/brakelight does not work the lamp may need to be
replaced.
1. Remove the taillight lens
cover mounting screws (1).
Remove the lens cover (2) and
gasket and set aside for
reassembly.
2. Remove the lamp (3) and
replace it with a new lamp.
3. Test the taillight/brakelight to
see that it’s working.
4. Reinstall the gasket and lens cover.
1
1
2
3
