Page #120 background imageLoading...
Page #120 background image
118
SPECIFICATIONS
SPORTSMAN 600
Gross Vehicle Weight 1240 lbs/563kgs
Fuel Capacity 4.75 gallons/17.98 liters
Towing Capacity 1500 lbs/681 kgs
Hitch Tongue Capacity 150 lbs/68.1 kgs (Rear rack capacity and
tongue weight not to exceed 200 lbs/90.7 kgs)
Front Rack Capacity 100 lbs/45.4 kgs
Rear Rack Capacity 200 lbs/90.8 kgs
Overall Length 85 in/215.9 cm
Overall Width 46 in/116.8 cm
Overall Height 47 in/119.4 cm
Wheelbase 50.75 in/128.9 cm
Ground Clearance 11 in/27.9 cm
Dry Weight 740 lbs/336 kgs
Minimum Turning Radius 76 in/193 cm unloaded
Engine Oil Capacity Two quarts/1.89 liters
Coolant Capacity 3.2 quarts/3.02 liters
Engine EH059OLE021
Displacement 597
Bore x Stroke 76.5 x 65
Pilot Jet 45
Main Jet 155
Needle Jet P-4
Jet Needle J8-4FA01-3
Pilot Screw 1.5
Alternator Output 300 Watts @ 3000 rpm
Compression Ratio 10.3:1
Starting System Electric
Carburetor BST 34mm
Ignition System CDI
Ignition Timing 25° @ 3000 +/-- 500 RPM
SparkPlug/Gap RC7YC/0.9mm/.035in
Lubrication System Pressurized Wet Sump
Driving System Type 4 Wheel Independent Shaft
