8.71
Steering and Suspensions
8
2010-2011 RTS Spring Guide
The stock rear track spring is a 190#/inch spring. The
stock
spring will accommodate most riders weighing
between 120 and 250 lbs. (54-113 kg).
Two additional accessory springs are available for riders
wh
ose weight is at the lowest or highest settings for the
190 spring.
All of the springs, spring gauge tools, and spring preload
mea
surements using a tape measure are provided in the
RTS Spring Guide Table below.
NOTE: Use a tape measure in the same manner as a
gaug
e tool with the end of the tape against the
spring tension adjuster knob and the preload
measurement length at the shock-body cap parting
line.
2010-2011 RTS Spring Guide Table
STOCK 190 SPRING
120 - 250 LBS.
120 LWT SPRING
90 - 155 LBS.
260 HD SPRING
240+ LBS.
SPRING PN =
2
010=7043572-385
2011 = 7043572-133
SPRING PN = 7041575-385 SPRING PN = 7043585-385
STOCK SPRING GAUGE PN
20
10 = 5253792
2011 = 5254748
LWT SPRING GAUGE PN
2010 = 5253854
2011 = 5254749
HD SPRING GAUGE PN
2010 = 5253855
2011 = 5254750
Rider Weight Preload Rider Weight Preload Rider Weight Preload
lbs. kg in. cm lbs. kg in. cm lbs. kg in. cm
120 54
2 5/8
MI
N
6.7
MIN
90 41
2 5/8
MIN
6.7
MI
N
240 109
2 3/8
MIN
6.0
MIN
130 59 2 3/4 7.0 95 43 2 3/4 7.0 255 116 2 1/2 6.3
140 64 2 7/8 7.3 100 45 2 7/8 7.3 270 122 2 5/8 6.7
150 68 3 7.6 105 48 3 7.6 280 127 2 3/4 7.0
160 73 3 1/8 7.9 110 50 3 1/8 7.9 295 134 2 7/8 7.3
170 77 3 1/4 8.3 115 52 3 1/4 8.3 310 141 3 7.6
180 82 3 3/8 8.6 120 54 3 3/8 8.6 320 145 3 1/8 7.9
190 86 3 1/2 8.9 125 57 3 1/2 8.9 335 152
3 1/4
MAX
8.3
MAX
200 91 3 5/8 9.2 130 59 3 5/8
9.2
210 95 3 3/4 9.5 135 61 3 3/4 9.5
220 100 3 7/8 9.8 140 64 3 7/8 9.8
230 104 4 10.1 150 68 4 10.1
240 109 4 1/8 10.5 155 70
4 1/8
MAX
10.5
MAX
250 113
4 1/4
MA
X
10.8
MAX
DO NOT ADJUST SPRING PRELOAD PAST THE MINIMUM
OR MAXIMUM SETTINGS LISTED FOR EACH SPRING.
