108
MAINTENANCE
Chaincase Oil (if equipped)
Oil Change (Cover Drain Method)
1. Position the snowmobile on a
level surface.
2. Remove the two screws
securing the fender to the
chaincase.
3. Remove the right side panel.
If equipped with a battery,
remove the battery. See page
134.
4. Place a drain pan under the
chaincase.
5. Loosen (do not remove) the
chaincase cover screws.
6. Carefully pry the cover open.
NOTICE: DO NOT insert a
screwdriver or pry bar
between the cover and
chaincase. Seal damage
may occur.
7. Allow the oil to drain
completely.
8. Tighten the cover screws.
Torque: 6-10 ft-lbs (8-13 Nm)
9. Remove the fill plug. Clean all
metal shavings off the plug.
To Next Page
