94
MAINTENANCE AND LUBRICATION
Adjustments
Handlebars
If desired, the handlebars can be adjusted for rider preference.
WARNING
Improper adjustment of the handlebars or incorrect torquing of
the adjuster block tightening bolts can cause limited steering or
loosening of the handlebars, resulting in loss of control and
possible serious personal injury or death. Follow the adjustment
procedures exactly, or see your Polaris dealer for service.
1. Remove the instrument panel and locate
the handlebar bolts (1).
2. Loosen the four bolts and adjust the
handlebar to the desired height. Be
sure the handlebars do not contact the
gas tank or any other part of the
machine when turned fully to the left
or right.
3. Torque the front two bolts to 10-12 ft. lbs. (14-17 Nm), then torque
the rear two bolts. A gap of up t o 1/8” will remain at the rear
bolts.
1
