HITCH REMOVAL / INSTALLATION
1. To remove the hitch (if equipped), remove the cotter pin
q
and hitch pin
w
.
Remove the hitch, then reinstall the hitch pin
w
and secure the cotter pin
q
.
2. To install the hitch, remove the cotter pin
q
from the hitch pin and remove
the hitch pin
w
.
3. Install the hitch to the receiver.
4. Reinstall the hitch pin (from the left side of the hitch) through the bore of both
the receiver and the hitch.
5. Reinstall the cotter pin. Make sure the hitch assembly is secure at that the
cotter pin is properly engaged over the hitch pin.
7-WAY TRAILER CONNECTOR
The 7-way trailer connector
q
installed
on your vehicle meets the requirements
of European standard ISO 1724.
Improper electrical wiring changes can
result in damage to both vehicle and
trailer components. When in doubt
about your trailer connection, please
contact a qualified towbar specialist for
assistance.
50
FEATURES AND CONTROLS
