TRACTOR MODELS ONLY
REAR HITCH
NOTICE
After 1000 km of use, tighten the bolt holding the trailer ball to the hitch to 445
N⋅m.
Use the rear hitch for towing a trailer. See the Hauling Cargo section for details
and procedures.
The values given below pertain to factory-installed hitches and are provided for
informational purposes only.
WARNING
Strictly follow the instructions outlined in the operator’s manual of the mounted
or trailed machinery or trailer, and not to operate the combination tractor —
machine or tractor — trailer unless all instructions have been followed.
IMPORTANT
For vehicle-specific trailering values, see the Specifications chapter.
The vehicle-specific values take precedent if they are lower than the
component values shown below.
REAR HITCH SPECIFICATIONS
Fasteners Metal pin with security cotter pin
Weld Length and Positions 7 mm fillet, all around
Maximum Vertical Load 100 kg applied on coupling point
Approval # E20-55R-01 3487
Per Tractor certification, maximum braked and unbraked trailer mass is 680 kg.
REAR HITCH CERTIFICATION LABEL
The hitch certification label is located near the hitch on models equipped with a
factory-installed rear hitch.
51
FEATURES AND CONTROLS
