ELECTRICAL
Specifications
Warning
Systems
Operating
Characteristics
Following
is
a
quick
reference
chart
showing
how
each
model
warns
the
operator
and/or
protects
the
engine
when
the
engine
overheats,
or
when
a
low
fuel
or
oil
condition
exists.
Year
2000
2000
2000
2000
2000
Model
Virage
TX
SLX
Pro
1200
Genesis
Genesis
FFI
Temp
Sensor
"ON"
@
F7C°
237±8°F/114°C
237±8°F/114°C
237±8°F/114°C
237+8°
F/114°
C
237±8°F/114°C
Light
(MFD)
Oil,
Heat,
Fuel
Oil,
Heat,
Fuel
Oil,
Heat,
Fuel
Oil,
Heat,
Fuel
Oil,
Heat,
Fuel
Some
models
limit
RPM
to
4500
in
the
event
of
an
overheat
or
low
fuel
condition.
Refer
to
the
chart
for
the
system
in
use
on
each
model.
Stator
Plate
Assembly
And
Ignition
System
Test
Specifications
All
specifications
are
listed
on
the
appropriate
wiring
diagram.
Refer
to
the
wiring
diagram
for
the
model
you
are
working
on.
If
resistance
specifications
are
not
listed
on
the
wiring
diagram,
use
specifications
listed
be
low.
Refer
to
test
procedures
in
this
section.
All
electrical
resistance
readings
should
be
done
at
room
temperature.
Reading
may
vary
±
10%.
Disconnect
component
to
be
tested.
Always
subtract
meter
lead
resistance
when
measuring
small
resistance
values.
Meter
readings
were
obtained
using
either
a
Fluke™ 73
or
Tektronix™
DMM155
digital
multitester.
Use
of
other
meters
may
produce
different
results.
NOTE:
Most
meters
will
not
be
able
to
measure
a
resistance
this
low.
Touch
the
meter
leads
together,
view
your
meter,
and
record
this
reading.
Measure
the
alternator
coil
wire
connections,
or
the
primary
coil
connections
listed
above.
The
reading
should
be
the
same
as
what
you
recorded
when
the
meter
leads
were
shorted
together.
■r
Polaris
Sales
Inc.
7.3
3/00
