Step 7 - Fascia installation

2. Plug the OEM button panel

harness into the back of the

OEM button panel

1. Connect PLUG B & E into the

back of the RW50/15

interface screen

3. Make sure all the cables are

tucked away neatly before securing

into place.

4. Rest the unit in place, test all

features first and then gently push

fascia panel back into position

5. Plug the OEM Air conditioning

control harnesses into the back of

the air conditioning control panel

6. Gently push air conditioning

controls back in.

7. Reposition Glove Box

BT50 Installation Guide October 7-Rescue 8/10/2015 9:38 am Page 10
