B. IPOD & USB Cable
1. Remove glove box - gently push
in sides to release.
1. Attach GPS Antenna Bracket to
the back of RW50/15
Interface Screen
2. Place GPS Antenna on top of the-
Bracket
3. Connect Antenna Plug into the
back of the RW50/15
Interface Screen
13. Plug harness back into
instrument cluster panel and
remount.
2. Unclip OEM USB and AUX cable
for now, so that you can remove the
glove box completely.
3. Feed RW50/15 USB cable
from top section down into the
glove box area
C. External Antenna
14. Reinstall trim.
NOTE: please make sure the bottom
section of the trim goes underneath
the two reset dials.
12. Connect PLUG A into OEM
plug located in the TOP SECTION
& Connect PLUG C into OEM plug
located in the
CD HOUSING AREA
6
To Next Page
