ENGINE DISASSEMBLY / ASSEMBLY
4.612004 Four Stroke PWC Service Manual
Freshwater Circuit Cooling Hose Routings
FRESHWATER OUTLET HOSE
(FROM HEAT EXCHANGER TO OIL STORAGE TANK)
FRESHWATER OUTLET HOSE
(FROM INTERCOOLER TO HEAT
EXCHANGER)
FRESHWATER OUTLET HOSE
(FROM OIL STORAGE TANK TO
EXHAUST MANIFOLD / WATER
INJECT OR)
TEE FITTING (TO EXHAUST
COOLING WATER INJECTOR)
