ENGINE COOLANT HOSE
(FROM EXPANSION TANK
TO WA TER PUMP)
ENGINE COOLANT HOSE
(FROM THERMOSTAT HOUSING
TO HEAT EXCHANGER -- THER-
MOSTAT OPEN)
ENGINE COOLANT HOSE
(FROM HEAT EXCHANGER TO OIL
COOLER -- THERMOSTAT OPEN)
ENGINE COOLANT HOSE
(FROM WATER OUTLET RAIL TO
OIL TANK -- THERMOSTAT
CLOSED)
ENGINE DISASSEMBLY / ASSEMBLY
4.64
2004 Four Stroke PWC Service Manual
Internal Engine Coolant Hose Routing -- Right View
