ECU 300 (Black)
ECU 100 (Grey)
Coolant
Temperature Sensor
D4 Engine Tem pera tur e Gr ound
E4 Engine Temperature Signal
1
2
FUEL INJECTION / IGNITION / EXHAUST SYSTEMS
5.22
2004 Four Stroke PWC Service Manual
Engine Coolant Temperature Sensor Circuit
Circuit Trouble Codes
P -- Code Description Summary
P0116 Engine Temperature: Signal Error Indicates the engine temp. signal is outside an acceptable range,
but not shorted to ground or battery voltage.
P0117 Engine Temperature: Short to Ground The engine temp. signal is shorted to ground.
P0118 Engine Temperature: Open or Short to Battery The engine temp. signal is shorted to battery voltage.
