159
Maintenance
Toe Alignment
3. Tie a length of string between two stands as
shown in the illustration. Position the stands so
that the string is flush with the side of the rear
tire.
NOTE: If available, you may use a long straight-edge
instead of string.
4. Measure the distance from the string to the rim
at the front (1) and rear (2) of the front rim.
The rear measurement should be between 0"
and 1/16" (0-1.5 mm) more than the front mea-
surement.
5. Repeat the measurement procedure on the
other side of the vehicle.
NOTE: If you discover improper alignment, see your
Polaris dealer for service.
2
Stand
String
1
