170
Maintenance
Rear Suspension
Rebound Damping
Use a flat-blade screwdriver to make damping adjustments.
1. Locate the rebound damping clicker drum between the
lower spring seat and the lower shock mount.
2. Turn the clicker counter-clockwise (1) to decrease the
rebound damping. Turn the clicker clockwise (2) to
increase rebound damping.
NOTE: The rebound damping is factory set at 16 clicks from
fully closed. See Suspension Settings on page 166.
Clicker
2
1
