184
Specifications
Outlaw 525 S
Max. Weight Capacity 215 lbs./97.5 kg Pilot Jet #45
Dry Weight 375 lbs./170 kg Main Jet #138
Fuel Capacity 3.9 gal./14.8 l Clip Position 4
Overall Length 71.5 in./182 cm Jet Needle OBDVS
Overall Width 47.5 in./121 cm Alternator Output 200 w @ 3000 RPM
Overall Height 45 in./114 cm Compression Ratio 11:1
Wheelbase 50.5 in./128 cm Starting System Electric
Ground Clearance 5 in./13 cm Carburetor Keihin FCR-MX 39mm
Min. Turning Radius 67 in./170 cm Ignition System CDI
Engine Oil Capacity 1.9 qts./1.8 l Ignition Timing 25° +/- 3° @ 3500 RPM in
neutral
Coolant Capacity 2.25 qts./2.1 l Spark Plug Type NGK DCPR8E
Engine ES51KLE Spark Plug Gap 0.6 mm / .024 in.
Displacement 510 cc Lubrication System Dry Sump/Internal Reservoir
Bore x Stroke 95 x 72 mm
