67
Features and Controls
Footwell Riser
The removable footwell risers improve riding ergonomics and provide comfort for shorter
operators. An operator will also have better control of the ATV when both feet can remain
firmly planted on either the footwells or the risers. If the operator's legs are long enough to
comfortably reach the footwells without the risers, the risers can be removed.
1. Remove the rubber caps covering the screw
access holes.
2. Remove the screws and nuts securing the
footwell riser to the footwell.
3. Remove the riser.
4. Reverse the procedure to reinstall the foot-
well riser for shorter operators.
