BELT INSTALLATION
NOTE
Be sure to install belt in the same direction as it was removed.
1. With the clutch spreader tool
q
installed, loop the belt over the drive clutch
and over the driven clutch.
2. Rotate the driven clutch and walk the belt into the clutch.
3. Turn the clutch spreader tool counterclockwise to remove from the driven
clutch.
4. Rotate / spin the driven clutch and belt approximately 5-7 times to properly
seat the belt in the driven clutch.
122
MAINTENANCE
