DRIVELINE MODE SWITCH
The Driveline Mode Switch has three positions: All Wheel Drive (AWD),
Differential Lock/Two Wheel Drive (2WD) and Off (Turf Mode).
q
AWD: Press the top of the switch to
engage All Wheel Drive (AWD).
w
2WD: Move the switch to the center
position to lock the differential and operate in
two wheel drive (2WD).
e
TURF Mode: Press the bottom of the
switch for Turf Mode (unlocked differential
power). In Turf Mode, the rear drive wheels
operate independently (1WD) depending on
tire traction. This mode of operation is well
suited to turf driving or when active traction is
not needed.
HEATER CONTROL PANEL (IF EQUIPPED)
To operate the cab heater, rotate the fan control
q
to the desired fan speed
setting. The far left setting turns the fan off.
Adjust the temperature by rotating the temperature control
w
to the desired heat
setting. Rotate the control clockwise to increase heat or counter-clockwise to
decrease heat.
36
FEATURES AND CONTROLS
