EXPLODED VIEWS
EXPLODED VIEWS
18-Tooth Sprocket Kit / Ensemble barbotin 18 dents
13mm Hub Kit / Ensemble moyeu 13 mm
$
72548(1P>IWOEV@
7+5($'/2&.(5
ITEM # PART # DESCRIPTION QTY
A 2205433 K-SPROCKET, CMPLST, 18 TOOTH 1
1 -- SPROCKET-CMPLST XP, 18 TOOTH 1
2 -- HFSCS, M10-1.5X30, 10.9, ZP, TL, DIN6921 4
%
72548(1P>IWOEV@
7+5($'/2&.(5
ITEM # PART # DESCRIPTION QTY
B 2205434 K-HUB, CMPLST, 13mm 1
1 -- HUB-CMPLST XP 13mm, ASSY 1
2 -- HFSCS, M10-1.5X30, 10.9, ZP, TL, DIN6921 4
3 2205454 ERR, 35, 2.4, ZP, SHR-137 1
