Polaris PROSPECTOR PRO 2.0 User Manual

44
EXPLODED VIEWS
Cap Kit / Ensemble de bouchons
Decal Kit / Décalques
#
W
ITEM PART # DESCRIPTION QTY
W 2209516 K-CAPS, CMPLST 1
1 -- 2 LIPS CAP, 1 3/4” O.D. TUBE 1
2 -- 2 LIPS CAP, 2” O.D. TUBE (LDPE) 1
3 -- WHEEL CAP / CAPUCHON DE ROUE 12
4 -- HUB CAP POLARIS ASS’Y / CAP MOYEU POLARIS ASS. 1
5 -- WHEEL SEAL (25 ID X 42 OD) 4
6 -- ATV SHAFT SEAL 12
7 -- HHP, M10-1 1
#
X
ITEM PART # DESCRIPTION QTY
X 2209518 K- DECAL, CMPLST, ATV 2.0 / S-KIT DECALQUE, POLARIS ATV 2.0 1
1 -- STICKER - DO NOT LOOSEN / DÉCALQUE - NE PAS DESSERRER 1
2 -- STICKER, FRONT LEFT PICTOGRAM / DÉCALQUE PICTOGRAMME AVG 1
3 -- STICKER, FRONT RIGHT PICTOGRAM / DÉCALQUE PICTOGRAMME AVD 1
4 -- STICKER, REAR LEFT PICTOGRAM / DÉCALQUE PICTOGRAMME ARG 1
5 -- STICKER, REAR RIGHT PICTOGRAM / DÉCALQUE PICTOGRAMME ARD 1
6 -- STICKER WARNING / AUTOCOLLANT AVERTISSEMENT 1
7 -- STICKER PROSPECTOR PRO 2.0 / AUTOCOLLANT 1
8 -- POLARIS HUB CAP STICKER / AUTOCOLLANT CAP MOYEU POLARIS 1
