Polaris Quattro User Manual

English
7
1-3'
(30-90 cm)
1-3'
(30-90 cm)
1-3'
(30-90 cm)
1-3'
(30-90 cm)
i
4
Connect Hose Fitting and Adjust Floats
1. Place the hose nut (i) onto the end of the feed hose connector (j).
2. Push the hose assembly (d) onto the feed hose connector (j).
Water can be used to lubricate the hose.
• Tightly secure the hose nut (i) onto the hose assembly (d).
3.
3. Position the first hose float (k) up against the feed hose connector (j) and then space
hose floats 1-3 ft (30-90 cm) apart.
4.

Polaris Quattro Specifications

General

Type	Robotic
Pool Type	In-ground
Cleaning Coverage	Floor, Walls, and Waterline
Drive Mechanism	4-Wheel Drive
Warranty	2 years
Cable Length	60 ft
Hose Length	Not applicable (robotic)
Debris Intake	Large capacity
