86
SPECIFICATIONS
RANGER 400
Maximum Weight Capacity (includes weight of
operator, passenger, cargo, accessories)
1000 lbs. (454 kg)
Dry Weight 1050 lbs. (476 kg)
Test GVW - Rollover Protection System (ROPS) 2750 lbs. (1247 kg) per OSHA 29 CFR 1928.53
Fuel Capacity 8.8 gal. (33.3 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 2.25 qts. (2.4 l)
Overall Length 108 in. (274.3 cm)
Overall Width 56.5 in. (143.5 cm)
Overall Height 73 in. (185 cm)
Wheelbase 72 in. (183 cm)
Cargo Box Dimensions (Inside) 32 x 42 x 11.5 in. (81 x 107 x 29 cm)
Ground Clearance 10 in. (25.4 cm)
Min. Turning Radius 150 in. (381 cm)
Towing Capacity 1250 lbs. (567 kg)
Max. Cargo Box Load 500 lbs. (227 kg)
Engine 4 valve 4 stroke single cylinder with counter balance
Lubrication System Dry Sump
Cooling Liquid
Engine Oil 2W-50
Displacement 455 cc
Bore x Stroke (mm) 87.9 x 75
Pilot Jet 42.5
Main Jet 150
Needle Jet P-6 (829)
Jet Needle 4IB33
Air Screw 2.75
Alternator Output 250 W
Compression Ratio 9.7:1
Starting System Electric
Carburetor 34 mm
Ignition System CDI
Ignition Timing 30° @5000 RPM
Spark Plug NGK BKR6E
Front Suspension Strut w/8 in. (20.3 cm) of travel
Rear Suspension Independent w/9 in. (23 cm) of travel
Driving System Type PVT
Shift Type Single Lever (console)
Gear Reduction - Low 7.70:1
Gear Reduction - Reverse 7.00:1
Gear Reduction - High 4.12:1
Drive Ratio - Front 3.818:1
