87
SPECIFICATIONS
RANGER CREW 570 Full Size
Maximum Weight Capacity 1750 lbs. (795 kg) (including operator, passengers, cargo, accessories)
1350 lbs. (612 kg) (Models sold in California)
Dry Weight 1520 lbs. (689.46 kg)
Test GVW - Rollover Protection
System (ROPS)
3270 lbs. (1483.25 kg) per OSHA 29 CFR 1928.53
Fuel Capacity 8.8 gal. (33.3 L)
Engine Oil Capacity 2 qts. (1.9 L) with filter
Coolant Capacity 5 qts. (4.75 l)
Towing Capacity 1500 lbs. (680.4 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load* 1000 lbs. (454 kg)
600 lbs. (272 kg) (Models sold in California)
Overall Length 146 in. (370.84 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 76 in. (193 cm)
Wheelbase 107 in. (271.78 cm)
Cargo Box Dimensions (Inside) 36.5 x 54 x 11.5 in. (93 x 137 x 29 cm)
Ground Clearance 10.5 in. (26.7 cm)
Min. Turning Radius 214 in. (543.5 cm)
Engine Dual overhead cam, 4 valve 4 stroke single cylinder
Displacement 567 cc
Bore x Stroke 99mm x 73.6mm
Alternator Output 560 W @ 3000 RPM
Compression Ratio 10.5:1
Starting System Electric
Fuel System Electronic fuel injection
Ignition System Electronic
Spark Plug / Gap NGK MR7F / .031 in. (0.7-0.9 mm)
Front Suspension McPherson Strut w/9 in. (22.9 cm) of travel
Rear Suspension Independent w/10 in. (25.4 cm) of travel
Lubrication System Wet Sump
