Polaris RZR 570 2016 - Pad Inspection

9.28
9926813 R04 - 2013-2016 RZR 570 Service Manual
© Copyright Polaris Industries Inc.
7. Remove the inner brake pad. PAD INSPECTION
1. Clean the caliper with brake cleaner or alcohol.
2. Measure the thickness of the pad material. Replace
pads if worn beyond the service limit.
Rear Brake Pad Thickness:
New .298 ± .007″ (7.57 mm ± .178 mm)
Service Limit .180″ (4.6 mm)
BRAKE SYSTEM
