9.42
9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
30.Install BOC post valving.
NOTICE
Ensure retaining ring is fully installed and secure.
31.Install BOC piston and retaining ring.
32.Apply Loctite® primer to the body cap threads.
33.Install appropriate O-ring and apply a thin layer of
shock oil to the O-ring ONLY.
34.Install Bottom Out Cup into the body cap prior to
installing body (if equipped).
35.Apply Loctite® 638 to body two threads down and two
threads wide 360° around body.
36.Place body in clamp blocks and torque body cap to
100 ft-lbs (136 Nm) using body cap socket.
STEERING / SUSPENSION
