9
9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
9.43
37.Place body in block clamps parallel to the ground.
38.Replace both O-rings on DSC or LSC.
39.Torque DSC to 35 ft-lbs (47 Nm) or LSC to 12 ft-lbs
(16 Nm).
40.Apply Loctite® to LSC screw (if equipped).
41.Install LSC knob and torque screw to specification.
42.Install reservoir O-ring.
43.Apply thin layer of shock oil to O-ring.
44.Thread down reservoir with strap wrench and torque
to specification.
STEERING / SUSPENSION
