LABEL VALUE FUNCTION
EFI 10A Fuse Accessory Relay Coil, ECM
Wake-Up, Pump Relay Coil,
Chassis Relay Coil, Start Relay
Coil, EFI Relay Coil, Injectors,
SCM Relay Coil (optional), Lights
Relay Coil, Ignition Coil, Starter
Solenoid Coil, Brake Relay Coil
COIL 7.5A Fuse Ignition coils
FRONT DIFF 10A Fuse Front Differential
CHARGE 15A Fuse Battery Charge Port
Additional Fuses (if equipped)
SCM 10A Fuse Shock Control Module
SHOCK 15A Fuse Shock Power
PDM FUSE TROUBLESHOOTING
IMPORTANT
In the event of faults or intermittent power to functions connected to more than
just one fuse, a solution may be to replace one of the PDM fuses. This is
because power routes from the PDM fuses to different “downstream” fuses.
See the table below for details.
PDM FUSE “DOWNSTREAM” FUSES
PDM 1 (30A)
INST UNSW (7.5A)
LIGHTS (7.5A)
INTR ACCY (10A)
TREM BLK (10A)
PDM 2 (30A)
PWR PT1 (10A)
CHASSIS (7.5A)
SCM (10A)
SHOCK (15A)
PDM 3 (30A)
EFI (10A)
106
MAINTENANCE
