TIRE ROTATION
Tire rotation is
recommended for every
500-mile (805-km) interval.
Perform tire rotation on the
vehicle by the strategy as
shown.
AXLE AND WHEEL NUT TORQUE SPECIFICATIONS
Inspect the following items occasionally for tightness, and if they've been
loosened for maintenance service. Do not lubricate the stud or the lug nut.
Lug Nut
(Aluminum Wheels)
Front and Rear
148 ft-lbs
(200 N⋅m)
Hub Retaining Nut
Front and Rear
120 ft-lbs
(162.7 N⋅m)
WHEEL REMOVAL
1. Position the vehicle on a level surface.
2. Place the transmission in PARK.
3. Stop the engine.
4. Loosen the wheel nuts slightly.
5. Elevate the side of the vehicle by placing a suitable stand under the frame.
Follow safe jacking procedures.
6. Remove the wheel lug nuts. Remove the wheel.
127
MAINTENANCE
