Polaris RZR S 1000 2016 User Manual

7.2
9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
GENERAL INFORMATION
TORQUE SPECIFICATIONS
COMPONENT TORQUE
Ball Joint Fasteners
42 ft-lb (57
Nm)
Bearing Carrier Mounting Fasteners
42 ft-lb (57
Nm)
Front Gearcase Cover Plate Screws
11 ft-lbs (15
Nm)
Front Gearcase Fill / Drain Plugs
10 ft-lbs (14
Nm)
Front Gearcase Mounting Bolts
33 ft-lbs (45
Nm)
Hub Castle Nuts
180 ft-lbs (244
Nm)
Prop Shaft Support Bearing
Fasteners
33 ft-lb (45
Nm)
Wheel Lug Nuts 48 in-lb (5 Nm)
SPECIAL TOOLS
PART
NUMBER
TOOL DESCRIPTION
2870026
CV Boot Clamp Pliers (earless type)
2872608 Roll Pin Removal Tool
PU-48951
Axle Boot Clamp Tool
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com/
FINAL DRIVE
