9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service

Manual

7.9

6. Torque wheel hub nut to specification and install a

new cotter pin

. Tighten nut slightly if necessary to

align cotter pin slot.

TORQUE

Hub Castle Nut:

180 ft-lbs (244 Nm)

7. Install wheel and four wheel nuts finger tight. Lower

vehicle and torque wheel nuts to specification.

TORQUE

Wheel Lug Nuts:

Aluminum: 120 ft-lbs (163 Nm)

Steel: 60 ft-lb (81 Nm)

8. Rotate wheel and check for smooth operation. Bend

both ends of the cotter pin around the end of the

spindle.

FINAL DRIVE
