SHOCK ADJUSTMENTS
Driver + 2
40 lbs.
18 kg
Factory default preload
Driver + 3
40 lbs.
18 kg
Add 0.4 inch (10 mm)
preload, front and rear
FRONT / REAR SPRING PRELOAD ADJUSTMENT
1. Elevate the vehicle to allow the suspension to fully extend.
2. Turn the adjusting ring to the left to add preload. Turn the adjusting ring to the
right to remove preload.
WARNING
Uneven adjustment may cause poor handling of the vehicle, which could result
in an accident. Always adjust both the left and right spring preloads equally or
have your POLARIS dealer or qualified person perform the adjustments.
DYNAMIX SHOCKS
q
Front Shock Preload Measurement
w
Rear Shock Preload Measurement
170
MAINTENANCE
