30
FEATURES AND CONTROLS
Passenger Seat
Always make sure the passenger seat lock-out is functioning properly
before operating with a passenger.
Do not operate the vehicle with the seat in the 2-up position when oper-
ating without a passenger. Always return the seat to the 1-up position for
single-rider operation.
Never carry cargo in the rear box when operating the vehicle in the 2-up
mode with a passenger.
Seat Conversion
1. Make sure the cargo box dump lever is securely latched.
2. Rotate both operator backrest latches 1/4 turn to release the locks.
3. Tilt the backrest slightly forward.
4. Pull the passenger backrest upward from the bed of the cargo box.
Dump Lever
Passenger
Backrest
Operator Backrest Latches
(view from front)
Locked
Unlocked
To Next Page
