No. Part # Description Qty
1 9-100-1014 All-Purpose Bag 1
2 9-100-1152 Housing, Turbine Upper 1
3 9-100-1114 Hub Cap 3
4 9-100-5107 E-clip, Stainless Steel 10
5 9-100-1108 Ball Bearing 8
6 C-10 Tire, MaxTrax
™
, White 3
7 9-100-1008 Wheel, Double-side 2
8 9-100-1017 Belt Kit, Small and Large 1
9 9-100-7011 Shield, Bearing 3
10 9-100-1005 Frame 1
11 9-100-5125 Screw, 8-32 x 1/2" SS Pan Head 11
12 9-100-1139 Axle Block Assembly 2
13 9-100-1010 Belt Divider, Transfer Pulley 1
14 9-100-3135 Collar, Bag Tie 1
15 9-100-1007 Transfer Pulley/Drive Shaft Assembly 1
16 9-100-5115 Screw, 8-32 x 3/4" SS Pan Head 5
17 9-100-5130 Lock Washer, Axle Block 4
18 9-100-1132 Drive Train Gear Kit with Turbine Bearing 1
19 9-100-1103 Turbine Wheel with Bearing 1
20 9-100-1116 Wheel, Single-side 1
21 C-131 Thrust Jet Kit 1
22 9-100-7008 Sweep Hose Barb Complete 1
23 B-20 Adjustment Screw, Sweep Hose 1
24 B-15 Sweep Hose Attach Clamp, White 1
25 9-100-3005 Base Weight 1
26 9-100-7170 Hose Clamp for WMS 6
27 9-100-7009 Jet Retainer 2
28 9-100-7014 Water Management System (WMS) 1
29 9-100-1155 Housing, Turbine Lower 1
30 9-100-3105 Sweep Hose Scrubber 1
31 9-100-5132 O-ring, In-head Timer/Feed Pipe Assembly 1
32 9-100-7030 Top and Base Assembly 1
33 9-100-1002 Feed Pipe/Timer Blank Assembly 1
34 A-20 Float, Head 1
35 9-100-1011 Sweep Hose Complete 1
36 B-10 Wear Rings 7
