SECTION 4 - MODEL 636 DISASSEMBLY AND REASSEMBLY
Tools needed
Dump Probe P/N 11604
Universal Flex Remover Tool P/N 12601
Strobe Housing Removal Tool P/N 12633-2
Viewfinder Panel Remover P/N 12552-3
Contact Removal Tool P/N 12536
3/32" diam. dowel pin (for Shutter Blade reassy)
Exacto knife with No. 11 blade
Soldering aid (“greenstick”) P/N 94168
Finger cots or lintless cotton gloves
Needlenose pliers
Tweezers and dental pick
Disassembly Note
No screws or threaded fasteners are used in the 636 Camera: most housings and piece parts of
sub-assemblies are held in position by detents, spring catches or tangs which engage bosses or
cutouts in corresponding mating parts. Careful “spring apart” techniques will free most parts of the
636.
Flex connecting tabs are held in their solderless contacts by internal spring contact pressure. Safe,
easy removal of the flex is done by inserting the appropriate size leg of Universal Tool 12601 into
the connector. This releases the grip of the internal contacts and allows the flex to be pulled out
together with the removal tool.
Contents of this Section Page
Strobe Disassembly 37
Strobe Reassembly 41
Apron Disassembly 42
Close Up Lens Disassembly 44
Close Up Lens Reassembly 45
Body Disassembly 46
Body Reassembly 48
Shutter Disassembly 49
Shutter Reassembly 55
Drive Disassembly 61
Drive Reassembly 66
Door/Spread Sys. Disassembly 71
Reassembly completion 72
Note: Reassembly instructions are listed in the contents above, only if they include specific,
detailed steps (in contrast to simply replacing parts removed).
36
