- 18 -
System Connections
Connecting To the Power Adapter
This unit is powered via the switching power adapter (supplied). See the below figure
for details:
1. Connect the AC adapter to jack marked with “DC 12V IN” on the rear panel of the
unit.
2. Plug the two-prong end of the power cord to the grounded electrical socket.
3. When not using the unit, turn off the power of the unit first, and then unplug the
power supply to prevent malfunctions.
