- 34 -
Specifications
LCD Screen Size 7 inches
Laser Wavelength Wavelength: 780/650nm
Video System NTSC
Frequency Response 20Hz~20kHz ±2.5dB
Audio Signal-to-Noise ≥ 85 dB
Audio Distortion + Noise ≤ -70dB (1KHz)
Channel Separation ≥ 70dB (1KHz)
Dynamic Range ≥ 80dB (1KHz)
System PLL
AM 520~1710kHz
Radio
Frequency
Range
FM 87.5~107.9MHz
Power AC100V~ 240V, 50/60Hz
Power Consumption ≤30W
Dimensions 3.1”H X 13.6”W X 11.2”D
Weight About 6.4 lbs.
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works.
© 1992 -1997 Dolby Laboratories, Inc.
All rights reserved.
For service, support and warranty information, visit www.polaroid.com or in the
US call 1-866-289-5168 and in Canada call 1-866-301-7922.
“Polaroid” and “Polaroid Pixel” are registered trademarks of Polaroid
Corporation, Waltham, MA USA.
