Polimaster PM1621M - ATTACHMENT a Overall Dimensions. Effective Center of the Detector

ATTACHMENT A
(reference)
OVERALL DIMENSIONS, EFFECTIVE CENTER OF THE INSTRUMENT DETECTOR
72 mm
8
7
m
m
Effective center
of the detector
35 mm
Graduation
direction
(
to radiation source
)
4
1
,
7
m
m
15 mm
Figure A.1
