Poly Rove B2 Configuration Guide

UAD settings
Log in to the PBXware's web administration interface.
Open a new browser window and enter the IP address in order to access the PBXware's web
■
administration login screen. Example: http://192.168.1.10.
Log in to PBXware with the e-mail address and password.
■
UAD Settings
Navigate to Settings: UAD.
■
Make sure that the Poly Rove B2 UAD is enabled. To check the UAD status, click the Edit icon
■
corresponding to the Poly Rove B2 device.
Make sure that Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to
■
Yes.
Click the Save button.
■
Creating an Extension
Creating Extension
Add the Extension
Navigate to Extensions. Click the Add Extension button.
■
The standard options window will be shown below.
■
Select the Poly Rove B2 device from the UAD select box.
■
Select Location: Local or Remote.
■
Local is for all Extensions registered on the LAN and Remote is for all Extensions
registered from remote networks, WAN, Internet, etc.
Click the Next step button.
■
Extension Values
Enter values into the required field text boxes.
REQUIRED FIELDS:
Name
■
Enter a name for the Extension being created. Example: John Smith.
E-mail
■

Poly Rove B2 Specifications

General

Caller ID	Yes
Connectivity	DECT
Battery	Lithium-ion
DECT Range	Up to 300 meters outdoors
Speakerphone	Yes
Frequency Band	1.9 GHz
Number of Handsets	1
Conference Calling	Yes
