The playable matrix of pads is laid out with the lowest note value being in the lower left pad
(pad 37), incrementing a semitone with each position to the right. If pad 37 were a C1, then
the next note on pad 38 would be a C#1, pad 39 would be a D1, and so on until pad 48 which
would be a B1.
How the adjacent pads change pitch depends on the chosen Layout from the Config menu.
Choose a pad, and the pad directly to the right will increase the pitch one semitone
regardless of the chosen Layout. For Layout 1, the pad directly above will increase the pitch 1
semitone. For Layout 2, the pad directly above will increase the pitch 2 semitones. For
Layout 4, (see the illustration) the pad directly above will increase the pitch 4 semitones.
