NOTICE: CUSTOMERS THAT PURCHASE POOLS MAY BE REQUIRED BY LOCAL OR STATE LAW TO
INCUR ADDITIONAL EXPENSES WHEN INSTALLING A POOL, IN ORDER TO COMPLY WITH STATE OR
LOCAL LAWS REGARDING FENCING AND OTHER SAFETY REQUIREMENTS. CUSTOMERS SHOULD CON-
TACT THEIR LOCAL BUILDING CODE ENFORCEMENT OFFICE FOR FURTHER DETAILS.
WARNING - VERY IMPORTANT! SITE MUST BE LEVEL, STABLE, COMPACTED SOIL.
• The pool must be assembled on a smooth and level site of firm soil that is free of stones, gravel, sticks,
black- top or other oil base compounds. Do not install pool on a wooden deck or any type of wooden
surface. You can not use sand and/or uncompacted soil to provide a level surface for this pool; it will
only wash out.
• FAILURE TO FOLLOW THE INSTRUCTIONS BELOW WILL CAUSE POOL TO COLLAPSE AND
WILL VOID THE WARRANTY!
3 4
WARNING: DO NOT overfill the pool and / or allow people to lay over or sit on pool wall doing so
can cause permanent injury. DRAIN pool to the proper level after a heavy rain.
TIP: It will be much easier to install your pool if you unfold it and let it lay in direct sunlight for about 2
hours prior to installation. This will help to insure a wrinkle-free fit because the pool material will be
more pliable allowing it to stretch into shape during installation.
Competent supervision and knowledge of the safety requirements
is the only way to prevent drowning or permanent injury
in the use of this product!
Never leave young children unattended.
DANGER:
Do not attempt to assemble this pool in adverse weather conditions, such
as in high winds, strong gusts or when the temperature is below 60°F.
DANGER: POOL SET-UP
Should you encounter any problems, contact the Customer Service at (888) 919-0070 from 8 AM to 5 PM Mon. thru Fri.
EST. Extended operating days and hours during peak season requirements.
Should you encounter any problems, contact the Customer Service at (888) 919-0070 from 8 AM to 5 PM Mon. thru Fri.
EST. Extended operating days and hours during peak season requirements.
2 POOL INSTALLATION
IF YOUR POOL INCLUDED A
FILTER/PUMP SYSTEM, REFER
TO FILTER SYSTEM OWNER’S
MANUAL SECTION
IN THE SWIMMING
POOL FILTER SYSTEM
OWNER’S MANUAL,
INSTALL POWER FILTER AND THE
POOL WALL FITTINGS AS
DESCRIBED
RING POOL SETUP INSTRUCTION SHEET
1 SITE PREPARATION
13.The pool is subject to wear and deterioration. If not maintained properly, certain types of excessive or
accelerated deterioration can lead to failure of the pool structure that might release large quanti ties
of water that could cause bodily harm and property damage.
14.Above ground / onground residential swimming pools are for swimming and wading only. No diving
boards, slides or other equipment are to be added to an above ground / onground pool that in any
way indicates that an above ground / onground pool may be used or intended for diving or sliding
purposes.
15.Never allow horseplay, diving or jumping into or around the pool. Serious injury, paralysis or death,
could result when this rule is disregarded. DO NOT ALLOW anyone to swim alone without supervi-
sion.
16.Safety signs shall comply with requirements of ANSI-Z535 and to use signal wording.
17.The pool is to be assembled by an adult; care should be taken in the unpacking and assembly of the
pool, this pool may contain accessible potentially hazardous sharp edges or sharp points that are a
necessary part of the function of the pool.
18.Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate
use of CPR can make a lifesaving difference.
19.Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
20.Do not place pool near or under overhead electrical lines.
21.Remove pool ladders before leaving the pool. Children as young as 2 years have climbed up ladders
and into pools and drowned.
CONSUMER AWARENESS BOOKLETS
Contact: U.S. Consumer Product Safety Commission at www.CPSC.gov/cpscpub/pubs/pool/pdf, Pub.
#362 “Safety Barrier Guidelines for Home Pools”.
Contact: ASSOCIATION OF POOL & SPA PROFESSIONALS ( formerly NSPI) at - www.apsp.org/164/index.aspx
These titles are now available: “The Sensible Way To Enjoy Your Aboveground / Inground Swimming Pool”,
“Children Aren’t Waterproof”, “Pool and Spa Emergency Procedures For Infants’, Layers of Protection”, and
the “ANSI / NSPI-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs”.
A. Select a level area, and completely remove all debris, twigs, stones, etc. DO NOT select an area under
overhead electrical lines, trees or within 15 feet of a house, building, etc.
B. The pool shall be located a minimum distance of 6 ft (1.83 m) from any electrical receptacle.
C. All 125 volt, 15 and 20 ampere receptacles located within 20 ft (6.0 m) of the pool shall be protected by
a ground fault circuit interrupter (GFCI). The 20 ft (6 m) distance is measured via the shortest straight
line distance the supply cord would follow without piercing a floor, wall, ceiling, doorway, window, or
other permanent barrier.
D. Contact your local utilities, checking that no underground cables, telephone lines, gas lines, etc. run
beneath the area you have selected.
A. Carefully unfold the Quick Set® pool and inspect seams for
manufacturing defects. With the inflatable ring on the top side,
lay out the pool in the area selected, making sure the bottom
of the pool is both flat and round. If your pool included or you
are going to purchase a filter/pump system, position the intake/
outlet fitting locations so they are 10 to 21 feet from the electrical
outlet you plan to use for the pool pump.
B. Inflate the top ring. Squeeze the base of the valve stem to open
an internal check valve while inflating.
C. If your pool included a filter/pump system, following the
instructions under “Power Filter Installation” in the “Swimming
Pool Filter System” owner’s manual, install Pool Wall Fittings as described in Steps “A” - “C”. Plug the
return fitting (25) with the Return Fitting Plug (21). Install the Suction Fitting Cap (20) on the Suction
Fitting (16). Make sure the drain fitting is plugged securely and the cap is in place. Start filling the pool
with water.
NOTE: AFTER ABOUT 1- INCH OF WATER IS ON THE BOTTOM, STOP FILLING AND SMOOTH
WRINKLES OUT OF THE BOTTOM OF THE POOL WORKING THEM FROM THE CENTER OUTWARD.
BE SURE FLOOR OF POOL IS ROUND AND FLAT. Next pull the outer wall out from under the top ring,
all around the bottom of the pool, so that it fills evenly.
NOTE: IF MORE THAN 1-2 INCHES OF WATER COLLECTS ON ANY ONE SIDE BEFORE THE POOL
STARTS FILLING IN THE CENTER, THE POOL IS NOT LEVEL ENOUGH, AND MUST BE CORRECTED,
SEE “SITE PREPARATION”, ABOVE.
D. NOTE: THE WEIGHT OF THE WATER WILL PREVENT ADJUSTMENT AFTER THIS POINT.
E. Now, as you continue filling, the inflated ring will rise as the water deepens. Max. Water Level is the
bottom seam of the inflatable ring; this information is printed on the ring. Once this is done, refer back
to the “Swimming Pool Filter System” owner’s manual, and continue from Step “D” on through the rest
of the installation if you have a filter/pump system.
