G. IMPORTANT - We cannot over-stress the importance of proper and adequate daily chemical treatment. Chlorine
and pH levels must be maintained at all times. PUMP AND FILTER ALONE WILL NOT PREVENT ALGAE FROM
GROWING IN POOL WATER; THIS CAN ONLY BE DONE BY MAINTAINING PROPER CHLORINE AND pH
LEVELS AT ALL TIMES.
.
Maintain pH level between 7.3 and 7.8.
.
Maintain chlorine level between 1.0 and 1.6 ppm (parts per million).
.
Superchlorinate your pool at least every other week.
A. Hot weather/heavy use may require pH and chlorine levels to be maintained on the upper side of the scale and
superchlorination of the pool every week.
B. Using a pool cover and/or solar cover will assist in maintaining your pH and chlorine levels by reducing the
amount of evaporation from your pool.
A. First, unplug the Power Filter. Now remove the RF Diverter Fitting (28) from the Return Fitting (RF) and then plug
the Return Fitting (25) with the RF Plug (21). Now thread the Water Cap (20) onto the Suction Fitting (16) and
hand tighten it only!
B. Slowly unscrew the Vent Screw (11) from the Seal Top (9) allowing the filter system to depressurize.
C. Remove the Seal Top Retainer (10) by turning counter-clockwise to unscrew. Remove the Seal Top (9).
Remove the Filter Cartridge (15) and remove any chlorine tablets left inside the core section of the filter.
D. Loosen all four Hose Clamps (14), remove the Suction and Return Hoses (12, 13) and allow water to drain out.
E. Clean and dry all filter pump parts including filter cartridges.
F. Liberally lubricate the O-rings (22), at the Seal Top (9) and (23) on the Vent Screw (11), with petroleum jelly, and
then reassemble it along with the Seal Top (9), Seal Top Retainer (10), Vent Screw (11) onto the Filter Case (8).
Store all filter parts carefully.
NOTE:
SYMPTOM PROBLEM POSSIBLE SOLUTION
1 Motor fails to start or A Unit Not Plugged In A Unit must be plugged into a 3-wire grounded outlet.
kicks on and off. B GFCI Breaker Tripped B Reset circuit breaker. If problem persists, have an electrician check circuit.
C Low Voltage C Check line voltage - must be 105 to 125 AC volts.
2 No flow or low flow A Low Water Level A Water depth must be no more than 2” from the bottom of inflatable ring or it
through return hose must cover the intake by at least 4”.
B Inlet / Discharge Clogged B Check for obstructions at suction fitting and in return hose.
C Filter Dirty C Clean (see page #5) or replace cartridge. Spare cartridges make service more convenient.
3 Filter is not cleaning pool A Chlorine Level A Maintain chlorine level between 1.0 and 1.6 ppm
(water cloudy, green, etc.) B Filter Dirty
B Clean (see page #5) or replace cartridge. Spare cartridges make service more convenient.
C pH Level C Maintain pH Level between 7.3 and 7.8.
D Cartridge Damaged D Check cartridge for damage and/or holes. Replace if damaged.
E Low Water Flow E Check for obstructions at suction fitting and in return hose fitting.
F Other Chemicals Required F Have water tested at pool supply store. It may be necessary to add other chemicals
due to varying water quality in different localities.
G Pool Water Very Dirty G Run pump more often, but never when pool is in use. Clean filter more often.
4 Water Leakage A Suction Hose / Return Hose A Adjust hose clamp (14) on cuff. Check O-ring (24) and retighten. Check hose for
any holes or cracks. Replace if needed. See page #3.
B Vent Screw in Seal Top B Check O-ring (23) for damage. Replace if needed. Lubricate with petroleum jelly.
C Seal Top Retainer/Seal Top C Check O-ring (22) for damage. Replace if needed. Lubricate with petroleum jelly.
D Pump to Volute Housing D Tighten screws.
E Volute Housing to Filter
E Check Volute Housing O-Ring for damage.
PROBLEMS: Should you encounter any problems, contact the Customer Service at (888) 919-0070.
Extended operating days and hours during peak season requirements.
8 POWER FILTER DISASSEMBLY AND STORAGE
7 TROUBLE SHOOTING GUIDE
DISCONNECT ELECTRICAL CORD BEFORE TROUBLESHOOTING FILTER
LIMITED WARRANTY
Polygroup Limited (Macao Commercial Offshore), (hereinafter “Polygroup”) warrants to the original purchaser only, the RP type Electric
Filter Pump against defects in material and workmanship for 180 days from the date of purchase. Original Purchaser must retain proof of
such purchase in the form of an original store sales receipt and must produce such upon request by Polygroup or its designated agents.
Warranty claims cannot be processed without a valid proof of purchase.
This Limited Warranty applies only to the original purchaser of the product and is limited solely to the repair or replacement of the
product, to be decided in Polygroup’s sole discretion. Consequential damages, including claims for loss of water, pool chemicals, damage,
or labor are not covered under this Limited Warranty.
This Warranty will be declared invalid should the Purchaser modify or repair the product themselves or by unauthorized persons; use
non-Polygroup parts or accessories with the product; use the product in contravention of the Manufacturers Instructions; use improper
voltage; abuse the product in any way; or through accident or negligence. Normal wear-and-tear is not covered under this Warranty, nor
are acts of God outside the control of Polygroup.
IN NO EVENT SHALL POLYGROUP, THEIR AUTHORIZED AGENTS, RELATED ENTITIES, OR EMPLOYEES BE LIABLE TO THE BUYER OR ANY
OTHER PARTY FOR DIRECT OR CONSEQUENTIAL DAMAGES. Some states or countries, or others jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
CAUTION - Concentrated chlorine levels and low pH levels will damage pool. You must follow the
instructions for the pool chemicals you use, as to quantity and recommended usage.
NEVER drop lumps or pellets of chemicals in pool; this may present a hazard to swimmers and/or damage your
liner.
