User’s manual
Thermostats that require a power supply can be wired into any of the 3 provided
connections. Two thermostats can be wired into the same connection allowing power to 6
thermostats. Thermostats can also be wired in a ‚daisy chain’ formation or powered by a
seperate electrical circuit, to allow power for upto 8 thermostats if required.
1 2 3 4 5 6 7 8
9
13
11
12
POWER SUPPLY 230V 50Hz
M
POWER SUPPLY 230V 50Hz
HEATING
DEVICE
M
10
