3-11
3 First Steps
Bottom view The bottom view of the scanning head is shown in the following figure.
Figure 3.9: Bottom view of the scanning head
1M6 mounting threads
For the mounting or adapter plate, e.g. for mounting on a tripod system
2 Mounting threads for quick release plate
For fluid head, for example for assembly on the tripod
3 Warning label
Information for correct assembly
3
1
2
1
22
