WARNING: To reduce the risk of serious personal injury, ALWAYS use proper hand
position.
WARNING: To reduce the risk of serious personal injury, ALWAYS hold securely in
anticipation of a sudden reaction.
5.1. Proper Hand Position
Proper hand position requires one hand on the main handle (I) fig. 1.
5.2. Tool Operation
Installing a blind rivet (fig. 8)
To install a blind rivet
• Place the blind rivet (Y) in the nose piece (A)
• Position the tool (fig.9)
• Pull and hold the switch (J) until the rivet is fully set in the application (fig. 10).
• When the blind rivet (Y) has been set completely, release the switch (J). The tool will return to its initial
position automatically. The mandrel is automatically dropped into the mandrel collector (W).
If you release the switch (J) before the end of the setting stroke, the tool will immediately return to its initial
position. If the blind rivet (Y) has not been set completely, repeat the previous steps.
Reset function (fig.9)
If the tool does not move to its initial position after releasing the switch or stops during the setting stroke,
reset the tool to home by quickly pulling and releasing the switch (J). If this does not resolve the issue, remove
the battery, re-insert and then repeat the prior step.
If the issue persists, contact your local service representative.
Emptying the mandrel collector (W) (fig. 6)
The mandrel collector is used to collect the waste mandrels. The mandrel collector must be emptied
depending on the size of the blind rivets used.
Approx. Capacity (PB2500)
• Tilt the tool back to allow all waste mandrels to fall into the mandrel collector.
• Open the mandrel collector (W) by sliding the Collector Lock (D) towards the nose housing nut (C) and
raise the cover (E).
• Empty the waste mandrels into an appropriate recycling container or waste bin
• To close the mandrel collector (W), lower the cover (E) until the Collector Lock (D) clicks into place.
