Porkka F - Page 13

13
P1
rE
5
5
1
15
15
2.00
P3
0
55
20
0
0.00
no
yes
yes
yes
AUS
OnF
OP
OP
dor
1
CL
EAL
0
0
FAn
yes
no
0
1
ntC
OFF
2
-20
Technical and Service manual
Porkka reserves the right to make product alterations at any time and can not be held responsible for any printing errors or omissions.
Inventus upright refrigerators and freezers
Alarm ALP Probe selection for temperature alarms
Alarm ALC Temperature alarms configuration
Alarm ALU Maximum temperature alarm (setpoint + value of ALU)
Alarm ALL Minimum temperature alarm (setpoint - value of ALL)
Alarm AFH Differential for temperature alarm recovery
Alarm ALd Temperature alarm delay
Alarm dot Temperature alarm delay (open door)
Alarm dAo Delay of temperature alarm at start up
Alarm AP2 Probe selection for condenser temperature alarms
Alarm AL2 Condenser low temperature alarm (not in use)
Alarm AU2 Condenser high temperature alarm
Alarm AH2 Differ. for condenser temp. alarm recovery
Alarm Ad2 Condenser temperature alarm delay
Alarm dA2 Delay of condenser temper. alarm at start up
Alarm bLL Compressor off for condenser low temperature alarm
Alarm AC2 Compressor off for condenser high temperature alarm
Alarm tbA Alarm relay switched off by pushing a key
Alarm bUM Buzzer switched off by pushing a key (not in use)
Configuration oA3 Condenser fan (third relay) configuration
Configuration oA4 Frame heater (fourth relay) configuration
Alarm AoP Alarm relay polarity
Digital inputs i1P Door switch polarity (digital input 1)
Digital inputs i1F Door switch configuration (digital input 1)
Digital inputs did Door switch alarm delay (digital input 1)
Digital inputs i2P Digital input 2 polarity (not in use)
Digital inputs i2F Digital input 2 configuration (not in use)
Digital inputs d2d Digital input 2 alarm delay (not in use)
Digital inputs nPS Number of activation of pressure switch (not in use)
Digital inputs odC Evaporator fan mode when door open
Alarm rrd Automatic restart with door open alarm
Energy Saving LES Light off during energy saving mode (not in use)
Energy Saving HES Differential for energy saving mode (not in use)
Other Adr TTL ModBus - serial address
Probes PbC Kind of probe
Configuration onF On/Off button configuration
Other dP1 Displaying value of air temperature probe
Other dP2 Displaying value of evaporator probe
Other dP3 Displaying value of condenser probe
Other dP4 Displaying value of probe 4 probe (not in use)
Other rSE Real Set point “SET + ES + SETd” (not in use)
Other rEL Firmware Release
Other Ptb Map code
Regulation SEt Set point
